40G to 10G QSFP40G-SFP10G 40G QSFP to 10G SFP Adapter CVR
The HiLink QSFP+ to SFP+ Adapter(QSA) Module offers 10 Gigabit Ethernet connectivity for Quad Small Form-Factor Pluggable(QSFP)-only platforms.
It allows smooth and cost-effective migration to 40Gigabit Ethernet by providing anoption touselower-speedEnhanced Small Form-Factor Pluggable(SFP+) modules in empty QSFP ports or when the other end of the networkis running at lower speeds.
Applications
Low EMI radiation Switches,serversand routers
Telecommunication and wireless infrastructure
Test and measurement equipment
Networked storage systems
Data Center networks
Storage area networks
Features
Trouble-free installation and network bring-up
Compliant to industry standards: QSFP+ MSA SFF-8436 / SFP+ MSA SFF-8431
Precision process control for minimization of pair-to-pair skew
1 independent duplex channels operating at 10Gbps, also support for 2.5Gbps, 5Gbps data rates
All-metal housing for superior EMI performance
100ohm differential impedance system
Operating case temperature: -20to 85℃
Low insertion loss
Low crosstalk
Secure latching mechanism
RoHS compliant
Real Picture
Order details
2~44Channels available. Com port: simplex or duplex. Fiber connector: LC/SC or other
Package: ABS plastic box, LGX metal cassette box, 19inch rack mount. DWDM Solutions and DWDM SFP/XFP.
Shipment & Payment 1. International Express: DHL, Fedex, UPS, EMS, UPS, TNT and etc. 2. Payment: T/T, Western Union, Paypal and so on.
Guarantee:
›& Brand new.
›& OEM/ODM is available. ›& 100% through quality test and aging test. ›& 3 years warranty (From the date of shipment).
Our Service
OEM/ODM order is available
We promise all the advertised optical modules are brand new and absolutely never use old and refurbished materials. All the optical modules have been through functional test and aging test. We provide 3 years warranty for all the optical transceivers from the date of shipment.
|
|
40G to 10G QSFP40G-SFP10G 40G QSFP to 10G SFP Adapter CVR Images
|
