Bidirectional SFP+ Transceiver Module 20KM TX1330nm / RX1270nm SM Datacom

Name: Bidirectional SFP Transceiver Module 20KM TX1330nm RX1270nm SM Datacom
Brand: HILINK
Price: 1 USD

Quality Bidirectional SFP+ Transceiver Module 20KM TX1330nm / RX1270nm SM Datacom wholesale

Brand Name : HILINK

Model Number : HL-SFP-BIDI-XXlr

Certification : CE FCC Rohs

Place of Origin : Guangdong, China

MOQ : 1pcs

Payment Terms : T/T, Western Union,Paypal

Supply Ability : 5000pcs/Week

Delivery Time : 2-7 working days

Packaging Details : Static bag, Plastic bag, Retail box

Product Name : WDM SFP 10G 20KM

Type : 10G BiDi SFP

Wavelength : 1270nm/1330nm

Distance : 20km

Connector : LC

Warranty : 3 years

Price : Negotiable

Contact Now

Bidirectional SFP+ Transceiver Module 20KM TX1330nm / RX1270nm SM Datacom

Hilink 10GBASE SFP+ BIDI 20KM modules Complaint with IEEE 802.3ae 10GBASE-LR,Electrical interface compliant to SFF-8431 specifications for enhanced 8.5 and 10 Gigabit SFP module “SFP+”,1270/1330nm DFB transmitter, PIN photo-detector,Simplex LC connector,2-wire interface for management specifications compliant with SFF 8472 digital diagnostic, Compliant with SFF8472 Digital Diagnostic Standard(DDM),ROHS

Features:

Hot-pluggable SFP+ footprint
Bidirectional 10G over single strand single mode fiber
Supports 9.95 to 10.5 Gb/s bit rates
Power dissipation <1W
RoHS-6 compliant (lead-free)
Extension temperature range -20°C to 75°C
Single 3.3V power supply
Maximum link length over 40km SMF
Uncooled DFB
Receiver limiting electrical interface
Single LC connector
Built-in digital diagnostic functions

Applications:

Fiber Channel Links

10giga Ethernet network

WDM transfer System

Quick view

P/N	SFP-WDMXX-20
Datarate	10G/ps
Wavelenth	1330nm/1270nm
Distance	20KM
Transmitter	DFB
Receiver	PIN
Mode Type	SMF
DDM/DOM	YES
Connector	LC Simplex
Application	WDM 10G Ethernet/ 2x 4x 8x FC
Operating Temperature	0℃~ +70℃
Voltage Supply	3.3V
Certification	CE/FCC/RoHS/
Brand	Hilink , CISCO OEM

10G SFP+ BiDi LC	SFP+ BiDi 10km	SFP+ BiDi 10km 1270nm/1330nm
	SFP+ BiDi 20km	SFP+ BiDi 20km 1270nm/1330nm
	SFP+ BiDi 40km	SFP+ BiDi 20km 1270nm/1330nm
	SFP+ BiDi 60km	SFP+ BiDi 60km 1270nm/1330nm
	SFP+ BiDi 80km	SFP+ BiDi 80km 1490nm/1550nm

Bidirectional SFP+ Transceiver Module 20KM TX1330nm / RX1270nm SM Datacom

Product Tags:

sfp+ optical transceive

sfp+ optical module

Bidirectional SFP+ Transceiver Module 20KM TX1330nm / RX1270nm SM Datacom Images
